Tandem Axle Open Rail
Tandem Axle Open Rail
A non-braking tandem-axle open-rail utility trailer introduced in May 2026. Curb weights — 6x12: 1,595 lb; 7x12: 1,684 lb; 7x14: 1,799 lb; 7x16: 1,914 lb; 7x18: 2,029 lb; 7x20: 2,144 lb.
Standard Features
- 12" high angle sides with 24" on-centre frame
- 3" tongue and 5×2 angle frame with tie-down holes
- Wood floor with toolbox mounting holes
- Lightweight 48-inch ramp on all widths
- 3,500 lb straight axle with 5-bolt hubs and EZ-Lube spindle
- Galvanized or powder-coated finish
- Sealed wiring harness with LED lights
- 205/75R15 LRC radial tires on 5-bolt galvanized wheels
- Spare tire mount
- Two 3,500 lb non-braking axles
- 2,000 lb A-frame setback jack
- 2 5/16" adjustable coupler with safety chains
Options
| Part # | Name |
|---|---|
| BT-FSR | Open Rail Front Side Bi-Fold Ramp |
| BT-RR | Open Rail 12×60 Removable Ramps |
| BT-BIF | Open Rail Rear Bi-Fold Ramp |
| BT-ALB | Open Rail Aluminum Toolbox |
| BT -BOF | Open Rail Front Brake Axle |
| BT-BOA | Open Rail Two Brake Axles |
| BT-15" Spare | Open Rail 205/75R15 Galvanized Spare |
| BT-205ALW | Open Rail 205/75R15 Aluminum Wheel |
Available Sizes & Finishes
6×12 — PaintedSKU: 1121-BT7212UDORLogin for pricing
